Twiga HXF 3300

The TWIGA HXF 3300 is the largest of the TWIGA HXF Range with an integrated 2.50m (8ft 2in) side boom extension. The HXF 3300 has been designed to be mounted onto industrial wheeled loaders and telehandlers. For added safety there is an inbuilt 45° hydraulic breakback and the unit is manually folded for transport. The TWIGA HXF 3300 is suitable for use with either the LRS2001 or the LRS2401 Quadsaw only and the HX Cutter Bar range.

Twiga HXF 3300 Specification

Reach with Quadsaw / Cutter Bar: 2.50m (8ft 2in)
Transport width: 2.20m (7ft 3in)
Mechanical folding for transport: Standard
Mechanical angle: Standard
Automatic break-back 44 degrees: Standard
Adjustment for crab steering: Standard
Left and right (left for telescopic loader): Standard
Flow divider (variable oil amount): Optional
Hydraulic angle: Optional
Danfos Flowdivider complete with E control for cutting angle and tool: Optional
Breaket for telescopic loader / front end loader: Optional

Attachments

Quadsaw

With a working width of 2.1 metres the quality LRS 2001 Quadsaw is ideal for managing heavy growth and tree limbs of up to 150mm (6”) diameter. Widely used throughout Europe the LRS2001 perfectly compliments the TWIGA FLEX Range of machines, giving exceptional cutting capacity on even the most stubborn growth with its four 500mm diameter cutting blades.

Also available for TWIGA FLEX Range mounting is the larger LRS 2401 Quadsaw which gives a wider cutting width and increased capacity in even tougher conditions. Capable of dealing with growth up to 250mm (9’’) the LRS 2401 provides extra vigour with four 600mm diameter cutting blades.

Cutterbar

The TWIGA FLEX Range can be specified with the HL150, HL180 or HL210 cutterbar. Offered in a length to suit your individual requirements and capable of cutting material up to 40mm in diameter, the HL cutterbar range is ideal when trimming back annual growth.

Also available on the TWIGA FLEX Range is the HX150 and HX225 cutterbar which offers increased cutting capacity at up to 100mm diameter. This range is ideal for making a clean cut on heavier growth.
